Hyundai Elantra MD/UD: Front Body C - 4Door. Front Body - Body Dimensions - Body (Interior and Exterior) - Hyundai Elantra MD 2010-2015 Service manualHyundai Elantra MD/UD: Front Body C

Engine mounting bracket hole (Ø12)

Transaxle mounting hole (Ø12)

Engine mounting bracket hole (Ø15)

Transaxle mounting hole (Ø13)

Front side member tooling hole (Ø9)

Front side member tooling hole (Ø6.6)
